| Applications: |
Robot |
| Packing Machines |
| Special Purpose Equiment |
| Process Machinery |
| Injection Moulding Machines |
| Transfer Lines |
| Automatic Workshop |
| Textile Machine |
| Panel Mount |
| Bottling & Filling Machines |
| Plastic Core: |
Nylon 30% Glass Filled |
| Contact Terminal: |
Brass, 6 micron Gold PTD |
| Lock Nut: |
Nylon + GF 70G33L HB |
| Waterproof: |
IP66, IP67, IP68 |
| Temperature Range: |
Connector Body -40°C to +105°C |
| Contact Resistance: |
≤10 mΩ |
| Insulation Resistance: |
≥100MΩ at DC 500V |
| Current Rating: |
20A |
| Breakdown Voltage: |
≥ AC 500V / 1 Minute |
