| Applications: |
Marine Electronic Devices |
| Telecommunications |
| Industrial Electrical Applications |
| CCTV |
| Security Monitor System |
| GPS |
| Robot |
| Lighting System |
| Connector Body: |
Nylon + GE, UL Recognized |
| Male Pin: |
Brass with Ni Plared / 6μ " Gold PTD |
| Waterproof: |
IP65, IP66, IP67, IP68 |
| Temperature Range: |
Connector Body -40°C to +105°C |
| Contact Resistance: |
≤10mΩ |
| Insulation Resistance: |
≥100mΩ at DC 500V |
| Current Rating: |
2A, 5A, 10A, 20A |
| Breakdown Voltage: |
≥ AC 1000V / 1 Minuute, ≥ 500V / 1 Minute (1.5A~5A) |
| Environmental Specification: |
48 Hours Salt Spray Contact |
| Durability: |
3000 Plug / Unplug Cycles Minimum |
