| Plastic Core: |
Nylon 101F NC010 UL94 |
| Contact Terminal: |
BSR-H 0.59D R-35 Silver PTD |
| Slide Ring: |
TEPCON M90 UL94V2 |
| Metal Cover: |
BSR-H 0.4t C2680 (65/35) Nickel |
| Lock Piece: |
BSR-H 0.4t C2680 (65/35) Nickel |
| Plastic Body: |
EVA UE633 |
| Spring: |
SW-C 0.6D Stain |
| Back Body: |
ABS PA-777D UL94 |
| Plastic Trail: |
PVC |
| Contact Resistance: |
30mΩ Max. |
| Dielectric Strength: |
250V AC / 1 Minute |
| Insulation Resistance: |
50MΩ Min. at 250V DC |
| Rating: |
100V AC 1A Max. |
| 12V DC 2A Max. |
| Insertion Force: |
4.5Kg Max. |
| Withdrawal Force: |
0.9Kg~3Kg |
